Kimplas Compression fittings PN 16 and are designed to use with all types of Polyethylene Pipes i.e. HDPE, MDPE and LDPE (grades PE100, PE80, PE63, PE 25 etc.). Unique design of the fitting facilitates insertion of the pipe into fitting without disassembling the fitting. The working temperature range of the fittings is - 5° to+ 40°C and the fittings are recommended for cold water services only. The fittings are ideally suited for Drip and Sprinkler Irrigation piping networks.

Standards:

• Pipe Compatibility: ISO:4427-2, EN:12201-2, IS:4984, DIN:8074, IS:12786
• Dimensions, Features & Functional Tests: IS0:3501, IS0:3503, IS0:3459
• Threading: IS:554, IS0:7/1, BS:21, DIN:2999
• Complies with ISO:14236

Download Datasheet
