Compression Coupler
Kimplas Compression fittings, PN 16 and are designed to use with all types of Polyethylene Pipes i.e. HDPE, MDPE (grades PE100, PE80, PE63, etc.). Unique design of the fitting facilitates insertion of the pipe into fitting without disassembling the fitting. The working temperature range of the fittings is - 5° to+ 40°C and the fittings are recommended for cold water services only. The fittings are ideally suited for connecting House Service Connections in Drinking Water Distribution piping networks. For exact recommendations on the applications and use, refer Kimplas Technical Specifications Manual.
Applications
Kimplas Compression fittings, PN 16 and are designed to use with all types of Polyethylene Pipes i.e. HDPE, MDPE (grades PE100, PE80, PE63, etc.). Unique design of the fitting facilitates insertion of the pipe into fitting without disassembling the fitting. The working temperature range of the fittings is - 5° to+ 40°C and the fittings are recommended for cold water services only. The fittings are ideally suited for connecting House Service Connections in Drinking Water Distribution piping networks. For exact recommendations on the applications and use, refer Kimplas Technical Specifications Manual.
| No | Size | Code | g | SP | A | B | C | E | L |
|---|---|---|---|---|---|---|---|---|---|
| 1 | 20mm | CC20BLA | 72 | 120 | 114 | 56 | 45 | 21 | 25 |
| 2 | 25mm | CC25BLA | 78 | 80 | 126 | 62 | 53 | 27 | 26 |
| 3 | 32mm | CC32BLA | 108 | 50 | 131 | 64 | 65 | 34 | 24 |
| 4 | 40mm | CC40BLA | 224 | 24 | 170 | 84 | 82 | 44 | 25 |
| 5 | 50mm | CC50BLA | 476 | 18 | 191 | 95 | 93 | 54 | 26 |
| 6 | 63mm | CC63BLA | 596 | 8 | 240 | 118 | 117 | 64 | 42 |
Standards: Pipe compatibility ISO :4427-2, EN:12201-2, IS: 4984, DIN: 8074 Dimensions, features & functional tests: ISO:3501, ISO:3503, ISO:3459 Complies with ISO:14236
