Micro Channel Drains
Micro Channel Drains provide a discreet, low-profile surface drainage solution for residential and commercial applications including pool surrounds, patios, and driveways.
PVC
Applications
Micro Channel Drains
Ideal for light flows, this effective solution comes as one integrated part, and channel sections snap together for a fast and easy install. Recessed grate openings facilitate runoff capture.
Description
- Micro Channel Drain and grate are one integrated piece; modular design makes it easy to customize layout
- Sleek, narrow 1-1/4 in.-wide channel design features recessed grate and grate openings parallel to channel length
- Micro Channel Drain with integrated grate are available in a variety of colors
- Micro Channel Drain and integrated Grate made of polyvinyl chloride (PVC)
- Treated with UV inhibitors to prevent fading and cracking
| Part Number | Description |
|---|---|
| 8001 | Micro Channel™ Drain and Integrated Grate, 1-1/4 in. wide X 10 ft. long, White Plastic, with Coupling |
| 8002 | Micro Channel™ Drain and Integrated Grate, 1-1/4 in. wide x 10 ft. long, Sand Plastic, with Coupling |
| 8003 | Micro Channel™ Drain and Integrated Grate, 1-1/4 in. wide x 10 ft. long, Gray Plastic, with Coupling |
| 8301 | Micro Channel™ Drain 45° Elbow and Integrated Grate, White Plastic |
| 8302 | Micro Channel™ Drain 45° Elbow and Integrated Grate, Sand Plastic |
| 8303 | Micro Channel™ Drain 45° Elbow and Integrated Grate, Gray Plastic |
| 8371 | Micro Channel™ Drain Tee and Integrated Grate, White Plastic |
| 8372 | Micro Channel™ Drain Tee and Integrated Grate, Sand Plastic |
| 8373 | Micro Channel™ Drain Tee and Integrated Grate, Gray Plastic |
| 8461 | Micro Channel™ Drain End Outlet, Connects to 1-1/4 in. and 1-1/2 in. Drain Pipes, White Plastic |
| 8462 | Micro Channel™ Drain End Outlet, Connects to 1-1/4 in. and 1-1/2 in. Drain Pipes, Sand Plastic |
| 8463 | Micro Channel™ Drain End Outlet, Connects to 1-1/4 in. and 1-1/2 in. Drain Pipes, Gray Plastic |
| 8472 | Micro Channel™ Drain End Plug, Sand Plastic |
| 8473 | Micro Channel™ Drain End Plug, Gray Plastic |
| 8471 | Micro Channel™ Drain End Plug, White Plastic |
| 8481 | Micro Channel™ Drain Coupling |
| 8502 | Micro Channel™ Drain with Bottom Outlet, 1-1/4 in. X 7 in., Connects to 1-1/4 and 1-1/2 in. Drain Pipes, Sand Plastic |
| 8503 | Micro Channel™ Drain with Bottom Outlet, 1-1/4 in. X 7 in., Connects to 1-1/4 and 1-1/2 in. Drain Pipes, Gray Plastic |
| 8501 | Micro Channel™ Drain with Bottom Outlet, 1-1/4 in. X 7 in., Connects to 1-1/4 and 1-1/2 in. Drain Pipes, White Plastic |
| 8511 | Micro Channel™ Drain and Integrated Grate Side Outlet, Connects to 1-1/4 and 1-1/2 in. Drain Pipes, White Plastic |
| 8512 | Micro Channel™ Drain and Integrated Grate Side Outlet, Connects to 1-1/4 and 1-1/2 in. Drain Pipes, Sand Plastic |
| 8513 | Micro Channel™ Drain and Integrated Grate Side Outlet, Connects to 1-1/4 and 1-1/2 in. Drain Pipes, Gray Plastic |
| 8601 | Micro Channel™ Drain Hold-Down Clips for Channel Stakes |
| 8651 | Micro Channel™ Drain Cleanout, Removable Top, White Plastic |
| 8652 | Micro Channel™ Drain Cleanout, Removable Top, Sand Plastic |
| 8653 | Micro Channel™ Drain Cleanout, Removable Top, Gray Plastic |
