BALL VALVE COMPRESSION - FEMALE THREADED
Applications
Kimplas UPVC Ball Valves are designed to use with PE, PVC and metal pipes. Kimplas PVC Ball Valves are ideally suited for connecting House Service Connections (HSC) piping networks. The Valves are recommended for Cold Water Services within temperature range of 0°C to 40°C. All types of Polyethylene Pipes i.e. HOPE, MOPE and LOPE (of grade PE100, PE80, PE63, PE 25 etc.) can be used with the Compression Female Threaded Valve. Unique design of the fitting facilitates insertion of the pipe into fitting without disassembling the fitting. For exact recommendations on use and applications, refer Kimplas Technical Specifications Manual
| d | DN | ITEM Code | g | SP | L | D | H | A | X" BSP | S1 |
|---|---|---|---|---|---|---|---|---|---|---|
| 20 | 15 | BVCF20X050BLA | 116 | 100 | 96 | 49 | 52 | 60 | 1/2" | 43 |
| 25 | 20 | BVCF25X075BLA | 184 | 65 | 115 | 60 | 58 | 65 | 3/4" | 54 |
| 32 | 25 | BVCF32X100BLA | 274 | 42 | 128 | 68 | 66 | 75 | 1" | 65 |
Standards:
Pipe compatibility: ISO :4427-2, EN:12201-2, IS:4984, DIN:8074 on compression side and threaded PVC/ Metal pipes on threading side. Dimensions, Features& Functional Tests: ISO:3501,ISO:3503,ISO:3459 Threading: IS:554, ISO:7/1, DIN:2999 Complies with ISO:1452- Part4 and ISO: 14236
