Plain - Female Threaded Ball Valve
Kimplas UPVC Ball Valves are designed to use with PVC and metal pipes. Kimplas PVC Ball Valves fittings are ideally suited for connecting House Service Connections (HSC) in Drinking Water Distribution piping networks. The Valves are recommended for Cold Water Services within temperature range of 0°C to 40°C. For exact recommendations on use and applications, refer Kimplas Technical Specifications Manual.
Applications
Kimplas UPVC Ball Valves are designed to use with PVC and metal pipes. Kimplas PVC Ball Valves fittings are ideally suited for connecting House Service Connections (HSC) in Drinking Water Distribution piping networks. The Valves are recommended for Cold Water Services within temperature range of 0°C to 40°C. For exact recommendations on use and applications, refer Kimplas Technical Specifications Manual.
| d | DN | ITEM Code | g | SP | L | D | H | A | X" BSP |
|---|---|---|---|---|---|---|---|---|---|
| 20 | 15 | BVPF20X050BKA | 90 | 150 | 66 | 49 | 52 | 60 | 1/2" |
| 25 | 20 | BVPF25X075BKA | 142 | 100 | 80 | 60 | 58 | 65 | 3/4" |
| 32 | 25 | BVPF32X100BKA | 210 | 60 | 90 | 68 | 66 | 75 | 1" |
Standards:
Pipe compatibility: Threaded PVC and metal pipes
Dimensions, Features&FunctionalTests:ISO:3501,ISO:3503, ISO:3459
Threading: IS:554, ISO:7/1, DIN:2999 Complies with ISO:1452 - Part 4
